Product Spotlights


Product Spotlights

PDF Documents Quick Reference

Image Document Name
ATRO and Steer King Join Forces ATRO and Steer King Join Forces
PS001-081020SK
CR00-67661 Carrier Bearing Assembly, Self-Aligning PS001-051220 CR00-67661 Carrier Bearing Assembly, Self-Aligning
PS001-051220
CR00-67661 Carrier Bearing Assembly, Self-Aligning Features and Benefits CR00-67661 Carrier Bearing Assembly, Self-Aligning
PS007-112420
CR00-67121 & CR00-67825 Carrier Bearing Assemblies PS009-080118 CR00-67121 & CR00-67825 Carrier Bearing Assemblies
PS009-080118
PB46-26268 Pivot Bushing (High Confinement) PS011-090117 PB46-26268 Pivot Bushing (High Confinement)
PS011-090117
ATRO Bumper Choices PS019-102418 ATRO Bumper Choices
PS019-102418
ATRO HT Motor Mounts and Insulator Kits PS012-092017 ATRO HT Motor Mounts and Insulator Kits
PS012-092017
ATRO Intraax/Vantraax Bushing PS007-060718 ATRO Intraax/Vantraax Bushing
PS007-060718
ATRO Kits Mack Camelback PS016-081018 ATRO Kits Mack Camelback
PS016-081018
ATRO Kits Haulmaax Suspension PS014-081018 ATRO Kits Haulmaax Suspension
PS014-081018
ATRO Kits HN Suspension PS015-081018 ATRO Kits HN Suspension
PS015-081018
ATRO Kits Kenworth Motor Mount Kit PS017-081418 ATRO Kits Kenworth Motor Mount Kit
PS017-081418
ATRO Mack Insulator Pads PS005-060120 ATRO Mack Insulator Pads
PS005-060120
ATRO Mack Pads PS004-040518 ATRO Mack Pads
PS004-040518
ATRO Small Eye Torque Rods vs. OE Small Eye Torque Rods PS003-090919 ATRO Small Eye Torque Rods vs. OE Small Eye Torque Rods
PS003-090919
Cement Mixer ATRO Parts EB38651 and EB38700 PS007-040115 Cement Mixer ATRO Parts EB38651 & EB38700
PS007-040115
Chalmers Aftermarket Replacement Parts PS005-082216 Chalmers Aftermarket Replacement Parts
PS005-082216
Chalmers Suspension PS018-101518 Chalmers Suspension
PS018-101518
Domed Style Trailer Bumpers PS006-040517 Domed Style Trailer Bumpers
PS006-040517
Expanded High Temperature Product Line PS004-060120 Expanded High Temperature Product Line
PS004-060120
Fontaine 5th Wheel Bushings and Kits PS004-091716 Fontaine 5th Wheel Bushings and Kits
PS004-091716
Hendrickson Auxiliary Axle Pivot Bushing Kits PS005-041318 Hendrickson Auxiliary Axle Pivot Bushing Kits
PS005-041318
Hendrickson Haulmaax ATRO LP50-24778 PS005-022615 Hendrickson Haulmaax ATRO LP50-24778
PS005-022615
Hendrickson HN Suspension PS008-072518 Hendrickson HN Suspension
PS008-072518
Kenworth AirGlide High Articulating Bushing PS006-051418 Kenworth AirGlide High Articulating Bushing
PS006-051418
Kenworth AirGlide Overview PS005-022217 Kenworth AirGlide Overview
PS005-022217
Neway ADZ and Volvo T-Ride V-Rod Assemblies PS013-091818 Neway ADZ and Volvo T-Ride V-Rod Assemblies
PS013-091818
Two-Piece Weldable Large Eye Torque Rods PS002-060419 Two-Piece Weldable Large Eye Torque Rods
PS002-060419
Two-Piece Weldable Small Eye Torque Rods PS003-060319 Two-Piece Weldable Small Eye Torque Rods
PS001-060319
Volvo T-Ride Suspension PS003-040418 Volvo T-Ride Suspension
PS003-040418
Watson & Chalin Lift Axle Kits PS006-071420 Watson & Chalin Lift Axle Kits
PS006-071420

CR00-67661 Carrier Bearing Assembly, Self-Aligning
PS007-112420

 View as PDF

Product Spotlight


ATRO CR00-67661 Carrier Bearing Assembly Features and Benefits ATRO CR00-67661 Carrier Bearing Assembly Features and Benefits PS007-112420

Two-Piece Weldable Small Eye Torque Rods
PS001-060319

 View as PDF

Product Spotlight


ATRO Two-Piece Weldable Small Eye Torque Rods Two-Piece Weldable Torque Rods Small Eye

ATRO and Steer King Join Forces
PS001-081020SK

 View as PDF

Product Spotlight


ATRO and Steer King Join Forces ATRO and Steer King Join Forces Top 10 Reasons to Buy

Watson & Chalin Lift Axle Kits
PS006-071420

 View as PDF

Product Spotlight


Watson & Chalin Lift Axle Kits

ATRO Mack Insulator Pads
PS005-060120

 View as PDF

Product Spotlight


Mack Insulator Pads

Expanded High Temperature Product Line
PS004-060120

 View as PDF

Product Spotlight


Expanded High Temperature Product Line

CR00-67661 Carrier Bearing Assembly, Self-Aligning
PS001-051220

 View as PDF

Product Spotlight


CR00-67661 Carrier Bearing Assembly, Self-Aligning PS001-051220

Domed Style Trailer Bumpers
PS006-040517

 View as PDF

Product Spotlight


PS006-040517 ATRO Polyurethane Domed Style Trailer Bumpers PS006-040517 Domed Style Trailer Bumpers

Neway ADZ and Volvo T-Ride V-Rod Assemblies
PS013-091818

 View as PDF

Product Spotlight


PS013-091818 Neway ADZ and Volvo T-Ride V-Rod Assemblies

Two-Piece Weldable Large Eye Torque Rods
PS002-060419

 View as PDF

Product Spotlight


Two Piece Torque Rods allow you to maintain a limited inventory with maximum flexibility. Match the male and female rods for lengths up to 27”. The ultimate in convenience.

ROD FEATURES:

  • Forged Rod Eyes
  • Heavier Rod Bar
  • 3 Year Warranty

  • Chemically Resistant
  • 3 Year Warranty

  • The free rotating bushing eliminates the clocking concerns.
  • This results in the need for less inventory and makes installation easier and quicker.
  • The bushing material last 2-5 times longer than rubber.
 Torque Rod Finder PS002-060419 Two-Piece Weldable Large Eye Torque Rods ATRO Two-Piece Weldable Large Eye Torque Rods PS002-060419

Volvo T-Ride Suspension
PS003-040418

 View as PDF

Product Spotlight


The Volvo T-Ride® suspension is for both on- and off-highway applications. It features a parabolic tapered spring pack that is upside-down and mounted outside the frame rails. There is a cushion that sits on each axle that is bolted to the end of each spring to absorb shock and vibration. Four lower torque rods control braking and acceleration forces. These suspensions are popular on waste haulers.

Benefits of ATRO Components

ATRO's T-Ride® components are chemically resistant to the common contaminants that most fleets face.

All T-Ride® torque rods and V-rod bushings have rotating pins for easier installation & elimination of torsional stress.

Load Spring:

  • Proprietary polyurethane formulated to absorb shock & dampen vibration improving ride quality

Lower Torque Rods:

  • Complete fixed length & adjustable torque rods, all with rotating pins for easier installation
  • OE lower torque rods rebushes with rotating TS96-22700 bushing for easier installation

Upper V-Rods:

  • TH96-22200 apex bushing uses a low friction, high abrasion & wear resistant polyurethane for durability & longevity
  • TS96-22600 & TS96-22286 end bushings have a split outer sleeve to ease installation & conform to inconsistent eye sizes
PS003-040418 Volvo T-Ride Suspension

ATRO Mack Pads
PS004-040518

 View as PDF

Product Spotlight


Mack Pads are manufactured using ATRO's proprietary polyurethane. The characteristics of this ATRO Poly formulation is Shock Absorbsion.

In contrast, rubber Mack Pads and other polyurethanes are made with a high rebound material. With the high deflection rate of this material, it can cause vibration and road shock. This energy can transfer to other suspension components, trunnion assemblies and the cab.

Positive Effects of ATRO Poly in Mack Pads:
  • Low Rebound, No Bounce Material
  • Shock Absorbing Material
  • Chemically Resistant to Contaminates
ATRO’s proprietary polyurethane takes the bounce out and acts to absorb shock, resulting in:
  • Smoother Ride
  • Longer Life and Extended Life of Attached Parts
  • Less Cab Damage
  • Reduction of T-Leaf Failure
PS004-040518 ATRO Mack Pads

Kenworth AirGlide Overview
PS005-022217

 View as PDF

Product Spotlight


ALUMINUM TORQUE ROD

Aluminum Torque Rods in V-Configuration Concerns:

  • Excessive conical forces from vertical pin alignment
  • Bushings with abnormal wear
  • Torque rods prone to breakage
  • Aluminum rod is weaker than steel
TR59-41474 Torque Rods Feature:
  • Stronger, more durable steel rod than aluminum rod
  • Forged steel rod eyes
  • Heavy-walled steel shaft
  • Contains High Articulating Bushings
Replaces:
  • Kenworth K195-472*
  • Kenworth K195-474
  • * no bushing
Torque Rod Contains:
Dimensions:
  • Length: 19 3/4” c-c
TS59-22400 Torque Rod Bushings Feature:
  • Articulation voids to provide extra vertical motion
  • Modified, oval pin design for improved articulation and conical movement
Replaces:
  • Kenworth 227720
  • Kenworth 836940
  • Kenworth 839310
Dimensions:
  • Length: 4 3/8” c-c
  • Outside Diameter: 2 3/4”
  • Bolt Hole: 5/8”

PS005-022217 Kenworth AirGlide Overview

Hendrickson Haulmaax ATRO LP50-24778
PS005-022615

 View as PDF

Product Spotlight


PROGRESSIVE LOAD SPRING

ATRO Part LP50-24778

In July 2014, Hendrickson began using their progressive load spring on all new production vehicles with the Haulmaax suspension. The overall height of the Progressive Load Spring is 4 1/4” in comparison to the Auxiliary Load Spring height of 3 5/16”. Because of the increased height of the progressive load spring, two auxiliary shims are typical instead of the 3 shims used on auxiliary load spring. When either load spring’s unloaded height measures less than 3”, the spring needs replaced.

ATRO’s Progressive Load Spring LP50-24778 is designed and engineered to be compatible with ATRO’s LP50-24179 Bolster Spring, providing maximum control and suspension performance. ATRO recommends removing or adding load spring shims (ATRO MS50-29791) to achieve the desired level of control and ride. Please refer to ATRO Progressive Load Spring Installation Instruction #DC001-022615. ATRO’s Progressive Load Spring will maintain contact with the shim plate at all times.

Note: In all cases, there must be at least one shim present per side.

ATRO’s Progressive Load Spring will replace the OEM load spring on newer trucks and can be retrofitted on older models to improve the suspension performance.

ATRO’s polyurethane material, coupled with ATRO’s design and engineering, will provide the fleet with:

  • Superior strength and durability
  • Resistance to chemical attack
  • Improved suspension performance and life

The LP50-24778 is also available in the following ATRO suspension kits:


PS005-022615 Hendrickson Haulmaax ATRO LP50-24778

Hendrickson Auxiliary Axle Pivot Bushing Kits
PS005-041318

 View as PDF

Product Spotlight


PS005-041318 Hendrickson Auxiliary Axle Pivot Bushing Kits

Chalmers Aftermarket Replacement Parts
PS005-082216

 View as PDF

Product Spotlight


PS005-082216 Chalmers Aftermarket Replacement Parts

Kenworth AirGlide High Articulating Bushing
PS006-051418

 View as PDF

Product Spotlight


Application: Kenworth Airglide 200/400/460/690

Aluminum Torque Rods in V-Configuration Concerns:

  • Excessive conical forces from vertical pin alignment
  • Bushings with abnormal wear
  • Torque rods prone to breakage
  • Aluminum rod is weaker than steel

TR59-41474

Torque Rods Feature:
  • Stronger, more durable steel rod than aluminum rod
  • Forged steel rod eyes
  • Heavy-walled steel shaft
  • Contains High Articulating Bushings
Replaces:
  • Kenworth K195-472*
  • Kenworth K195-474
  • * no bushing
Torque Rod Contains:
Dimensions:
  • Length: 19 3/4” c-c

TS59-22400

Torque Rod Bushings Feature:
  • Articulation voids to provide extra vertical motion
  • Modified, oval pin design for improved articulation and conical movement
Replaces:
  • Kenworth 227720
  • Kenworth 836940
  • Kenworth 839310
Dimensions:
  • Length: 4 3/8” c-c
  • Outside Diameter: 2 3/4”
  • Bolt Hole: 5/8”

TR57-44992

Complete Torque Rod with Bushings

TH57-22264

V-Rod Apex Hollow Mount Bushing
  • Available separately, without hardware
  • OE does NOT sell separately
Replaces:
  • Neway 90008264, 90008278
Dimensions:
  • Length: 7/8”
  • Inner Diameter: 1"
  • Outside Diameter: 2 3/4”

TR57-44645

V-Rod Rebush Kit
Replaces:
  • Holland/Neway SRK-645
  • Neway 48100511
Dimensions:
  • (2) TS59-22400 Bushings
  • (1) TH57-22264 Bushing
  • (2) Spacer Shims
  • (1) 1-8UNC x 6" Bolt & Locknut
  • (4) 5/8-11UNC x 3 3/4" Bolt/Locknut
  • (2) 1" Washers
  • (8) 5/8" Washers

PS006-051418 Kenworth AirGlide High Articulating Bushing

Cement Mixer ATRO Parts EB38651 & EB38700
PS007-040115

 View as PDF

Product Spotlight


Many concrete mixers employ a rear mounted “Stinger Axle” that drops down and makes contact with the pavement, usually powered down by a hydraulic cylinder. These “Booster Bridge Trailing Axles” are forced down to shift the load forward towards the front of the truck. This allows concrete mixers to maximize payload and meet local weight restrictions by improved weight distribution across the truck axles. These “drop down” axles on the rear of the mixer are often rigid suspensions. Being rigid they take a beating and ATRO’s stronger polyurethane material provide much longer life for the booster cylinder bushings mounted at the end of the cylinders. The EB38700 BridgeKing cylinder bushing has an extended outer sleeve to reduce cracking. Please see the diagram for the bushing locations.

There are several manufacturers of these suspensions. The following bushings are on popular applications:
  • ATRO #EB38700
  • Con-Tech #750051
  • Kimble #C9634375-03
  • BridgeKing Cylinder Pivot Bushing
  • ATRO #EB38651
  • McNeilus #0183488
  • McNeilus Booster Cylinder
Benefits of ATRO's polyurethane bushings.
  • Polyurethane material is twice as strong as rubber
  • It has 3-5 times the life of rubber bushings
  • Polyurethane is not affected by chemical attack including acidic cleaners

PS007-040115 Cement Mixer ATRO Parts EB38651 & EB38700

ATRO Intraax/Vantraax Bushing
PS007-060718

 View as PDF

Product Spotlight


DIRECT REPLACEMENT BUSHINGS

ATRO offers solutions for OE #S-24691, S-26321 and A6914.
  • Traditional tri-functional design
  • Voids like the standard rubber bushing.
  • Similar OD (5 7/8") to the rubber bushing (6") and like rubber is compressed into the beam hole which is 5 1/2" ID.
  • ATRO offers installation tool #PT50-59307 to install this bushing
  • The inner sleeve is bonded in place
PB50-36000
Replaces S-24691
  • Kit includes Hex box
  • Must torque to 500-550 ft-lbs.
PB50-36001
Replaces S-24691
  • Kit includes Shear Bolt
  • Shear bolt head snaps off at the proper torque
PB50-36100
Replaces S-24691
  • Kit does not include Bolt
  • Wear washers included
PB50-36321
Replaces S-26321
  • Kit includes Hex Bolt
  • Must torque to 500-550 ft-lbs
PB50-36322
Replaces S-26321
  • Kit includes Shear Bolt
  • Shear bolt head snaps off at the proper torque.
PB50-36914
Replaces A-6914
  • Kit includes Hex olt & Bolt Sleeve
  • Must torque to 775-825 ft-lbs.

 Swipe table right for columns.

ATRO P/NOE bushingVoidsInner pin rotationBolt typeHardware includedAlignmentInstall toolQty/axle
PB50-36000S-24691YesNoHex headYesQuick-AlignPT50-593072
PB50-36001S-24691YesNoShear BoltYesQuick-AlignPT50-593072
PB50-36100S-24691YesNon/aWear washers onlyQuick-AlignPT50-593072
PB50-36321S-26321YesNoHex headYesQuick-AlignPT50-597361
PB50-36322S-26321YesNoShear BoltYesQuick-AlignPT50-597361
PB50-36914A-6914YesNoHex headYesWelded AlignmentPT50-593072
Wear Items:

Tri-functional bushing

  • Mode of failure: bushing tube spacers melt, inner sleeve separated from rubber.
  • Cause: excessive vertical movement of suspension arm caused buildup of excessive heat.
  • Note: check to see if tires are out of balance or if shocks have failed.
Tech Tip:

ATRO's installation tools will install/remove OE bushings and/or ATRO bushings. Remove the alignment pins when installing/removing the ATRO "Easy Install" bushings which don't have voids. Conversely, the OE tool can be used to install/remove both OE and ATRO; simply remove alignment pins from the rear drive plate before attempting ATRO "Easy Install" installation/removal.

Installation Tool PT50-59307

Do not use an impact wrench on this tool. Must lubricate before use. Can be used to install/remove ATRO & rubber pivot bushing.

KEY ATRO ADVANTAGES

Impervious to chemical attack
  • Oil & Grease
  • Calcium Chloride (Winter Salt Melt)
  • Citric Acid & Acid Based Cleaners
  • Ethylene Glycol
  • Gas, Kerosene & Diesel Oil
  • Many More
ATRO'S polyurethane is 2-5x stronger than rubber
  • ATRO Polys are specifically engineered to the function of the part providing added durability and reliability to the suspension.
  • ATRO Polys maintains at least 2x or greater tensile and tear strength and 2x the elongation vs. rubber.
Proprietary Formulas
  • ATRO determines which of ATRO's proprietary polyurethane formulas best suit the part upon evaluation of its application, purpose and function.
  • As a result, ATRO Intraax bushings last longer and are backed up by a three year warranty.

PS007-060718 ATRO Intraax/Vantraax Bushing

Hendrickson HN Suspension
PS008-072518

 View as PDF

Product Spotlight


Designed for vocational uses including dump, refuse, mixer, construction and logging applications: 40k, 46k and 52k capacities.

This walking beam suspension features bar pin end bushings with no center bushings for the beams to pivot on. The traditional center bushing is replaced by 2 large bolster springs (4 per vehicle).

The transverse rod is critical, especially in high center of gravity applications like dump trucks, concrete mixers.

The auxiliary spring should be replaced if the spring itself measures less than 3” in height when the truck is unloaded.

BENEFITS OF ATRO COMPONENTS

Bolster and Auxiliary Springs:
  • Proprietary polyurethane formulated to absorb shock & dampen vibration for improved ride quality
  • Resistant to dynamic compression set
  • Chemically resistant to contaminants
Torque Rods:
  • ATRO’s 2-piece torque rods reduce inventory costs (cut to c-c length)
  • Rotating pin makes installation easier and eliminates torsional stresses
End Bushings:
  • Rotating bushing eliminates torsional stresses
  • Chemically resistant to contaminants
PS008-072518 Hendrickson HN suspension

Carrier Bearing Assemblies CR00-67121 & CR00-67825
PS009-080118

 View as PDF

Product Spotlight

COMPONENTFEATURESBENEFITS
Slotted InsulatorATRO's proprietary, high quality polyurethaneLonger Life Reduced Vibration Resistant to Chemicals (i.e. oil, fuel, road salt, cleaning solvents, etc.)
Sealed BearingPermanent, double sealKeeps contamination out Permanently lubricated
Bearing Dust ShieldZinc electroplating Sealed bearingCorrosion Resistant Protection from road debris
Steel Bracket10 gauge steel Zinc ElectroplatingStrength & Durability Corrosion Resistant

Installation Tip:

  • Remove and do not reinstall the original equipment dust shield.
    • Reusing the OEM's shield can cause noise and installation issues.
  • Thoroughly clean all mating surfaces prior to reassembly.
  • Hand tighten bolts to hold carrier bearing in place
  • Torque to manufacturers specifications (varies by application)
CR00-67121
Replaces:
  • 210121-1X: Autocar; International, Kenworth, Mack, Meritor, Spicer, Volvo
  • Blue Bird 00108533
  • Euclid E4001776
  • Ford C8HA-4800B; D4TZ-4800G
  • Gaff 40075
  • General Motors 2406989; 15616328
  • Mack 35MUA31; 35MUA32P1
  • Newstar S-1980
  • Spicer KCB121
UPC Code: 751354039269
CR00-67825
Replaces:
  • 210661-1X: Arvin Meritor, Autocar, Kenworth, Mack, Peterbilt, Spicer, Volvo
  • CB2106611XSA: Arvin Meritor, Autocar, International, Kenworth, Peterbilt, Volvo
  • Ford D4TZ4800J
  • Freightliner SP2106611X
  • Gaff 40074, 40197
  • GMC 15512196
  • International 283071C93
  • Mack 203SJ13
  • Spicer 5003323
UPC Code: 751354026870
Assembly
Part NumberDescriptionHeightWidthLength
CR00-67121Carrier Bearing Assembly, Series 17106 5/16"2 1/4"9 1/4"
CR00-67825Carrier Bearing Assembly, Series 18107 1/4"3"10"
Bearing
Part NumberDescriptionIDCenter HeightBolt HolesBolt Size
CR00-67121Carrier Bearing Assembly, Series 171050mm2 25/32"7 5/8" c-c1/2"
CR00-67825Carrier Bearing Assembly, Series 181060mm3 1/4"8 5/8" c-c1/2"

PS009-080118 Carrier Bearing Assemblies CR00-67121 & CR00-67825

PB46-26268 Pivot Bushing (High Confinement)
PS011-090117

 View as PDF

Product Spotlight


Problem:

  • When the drive axles rotate during braking and acceleration, the standard rubber bushed spring eye bushing will rotate in the leaf spring eye causing the eye to wear and the bushing to become loose.
  • The bushing tends to “walk” out of the spring eye towards the driver or curbside of the truck.
The PB46-26268 Solution:
  • The free rotating inner pin prevents the bushing from turning in the leaf spring eye, eliminating spring eye wear.
  • The inbound flange prevents the bushing from walking sideways out of the eye.

Note: The aftermarket (including ATRO) offers .060 oversized bushings to compensate for the spring eye wear. However, the leaf spring will eventually need replacement.

Freightliner FASII Airliner: 16-16412-000
Freightliner FASII Airliner: 16-18035-000
International Corp Air/Air Beam: 3538115C1
Kenworth AG400L: 52296
Peterbilt Low Low Air Leaf: 52296
Dimensions:
  • OD: 2 1/2"
  • Bolt Hole: 3/4"
  • Bolt Holes: 5 21/32" c-c
Qty Per Axle: 2

ASSOCIATED TORQUE RODS


PS011-090117 PB46-26268 Pivot Bushing

ATRO HT Motor Mounts and Insulator Kits
PS012-092017

 View as PDF

Product Spotlight


ATRO Solutions

A full line of engine mounts are available and in stock to fulfill your parts needs. ATRO High Temperature Engine mounts perform in the extreme conditions of EGR/SCR engine systems. The ATRO HT Formula is the only high temperature resistant polyurethane in the marketplace and greatly exceeds the performance of rubber. ATRO Parts providing Solutions for Heavy Trucks.

PL1017-HT Motor Mount (High Temperature)
Replaces:
  • Mack: 20QL1118A
  • Mack: 20QL1175
  • Mack: 25167342
Dimensions:
  • Length: 1 1/2"
  • ID: 3/4"
  • Small OD: 1 11/16"
  • Large OD: 3 3/16"

AVAILABLE IN KITS

KT62-62216-HT Insulator Kit (High Temperature)
Replaces:
  • Mack 204SX216
Contains:
  • (8) PL1017-HT Bushings
  • (8) Washers
  • (4) 3/4"-16 x 6 1/2" Bolts
  • (4) Locknuts
KT62-62389-HT Insulator Kit (High Temperature)
Replaces:
  • Mack 204SX389
Contains:
  • (8) PL1017-HT Bushings
  • (8) Washers
  • (4) 3/4"-16 x 5" Bolts
  • (4) Locknuts

AVAILABLE IN STANDARD ATRO POLYURETHANE

PL1017Motor Mount
Dimensions:
  • Length: 1 1/2"
  • ID: 3/4"
  • Small OD: 1 11/16"
  • Large OD: 3 3/16"
KT62-62216 Insulator Kit
Contains:
  • (8) PL1017 Bushings
  • (8) Washers
  • (4) 3/4"-16 x 6 1/2" Bolts
  • (4) Locknuts
KT62-62389 Insulator Kit
Contains:
  • (8) PL1017 Bushings
  • (8) Washers
  • (4) 3/4"-16 x 5" Bolts
  • (4) Locknuts

PS012-092017 ATRO HT Motor Mounts and Insulator Kits

ATRO Kits Haulmaax Suspension
PS014-081018

 View as PDF

Product Spotlight


KEY TO EFFICIENT REPAIRS COMES WITH HAVING THE RIGHT PARTS TO DO THE JOB.

  • Ensure you have all the right parts
  • One part number to stock
  • Steamline the ordering process

For additional information about the Haulmaax® kit and suspension or other popular kits and suspensions, visit the following:

  • www.atrobushing.com - Search “Haulmaax”
  • www.vimeo.com/user84803198
  • www.youtube.com - Search ATRO Bushing

Note: Replacing the center mounted progressive auxiliary spring with all bolster spring repairs is required. Failure to install the auxiliary spring or mixing ATRO suspension components with other manufacturer’s components will negatively affect ride quality and may cause premature failure of the bolster springs.

KT50-25002 Haulmaax® Suspension Kit
Contains:
  • (4) LP50-24179
    • 8-Bolster Springs; 4-Spacers;
    • 4-Flange Bolts; 36-Flange Nuts
  • (1) LP50-24902
    • 2-Progressive Load Springs;
    • 2-Shims; 6-Bolts; 6-Locknuts
KT50-25003 includes all components above PLUS (1) MS50-29891 (4-Wear Plates)
EB50-21013 Bar Pin Bushing Kit
Contains:
  • (1) Bar Pin Bushing
  • (2) Bolts
  • (2) Nuts
  • (4) Shims
  • (4) Washers
Key Part: Progressive Auxillary Spring
  • Load Spring is NOT an overload spring or bump stop
  • It is designed to carry up to 40% of the load
  • Properly installed, the auxiliary spring is in contact with the contact plate on the saddle 100% of the time
KT50-25004 Hendrickson HN Suspension Kit
Contains:
  • (1) LP50-24000
    • 2-Bolster Springs
  • (1) LP50-24974
    • 1-Spring Pad; 3-Bolts; 3-Locknuts
  • (16) Bolts, 7/16”-20x 1.25”
  • (16) Locknuts
  • (32) Flat Washers
SK62-50340 Mack Insulator Kit
Contains:
  • (1) SK50340-HW
    • 4-MA36500 Upper Pads;
    • 4-MA36000 Lower Pads;
    • 4-Bolts, 7/8”-9UNC 4”;
    • 2-Bolts, 7/8”-14UNF 5”;
    • 12-Locknuts; 16-Flat Washers
  • (8) MS62-29246 Insulator Spacer Blocks
KT62-62216-HT Mack Isolator Kit-High Temp
Replaces:
  • Mack 204SX216
CONTAINS:
  • (8) PL1017-HT Transmission Mounts
  • (4) Bolts
  • (8) Washers
  • (4) Locknuts
EM75-61001-HT Peterbilt Air Cooler Mount Kit-High Temp
Replaces:
  • Peterbilt MR1001 (Motor Mount ONLY
CONTAINS:
  • (4) Polyurethane Mount Bushings
  • (4) Polyurethane Washers
  • (4) Flat Washers
  • (8) Bolts
  • (4) Locknuts
PB00-26839 Lift Axle Bushing Kit
Replaces:
  • Various OEM R008839
  • (16) PB00-36314 Flange Bushings
  • (8) Inner Sleeves
  • (8) Bolts
  • (8) Flat Washers
  • (4) Locknuts
MM75-62001-HT Peterbilt Rear Motor Mount Kit-High Temp
Replaces:
  • Peterbilt MR1001 (Motor Mount ONLY)
CONTAINS:
  • (4) MM75-62372-HT Motor Mounts
  • (4) Bolts
  • (4) Snubber Washers
  • (8) Flat Washers
  • (4) Locknuts
Qty Per Axle: 2

PS014-081018 ATRO Kits Haulmaax Suspension

ATRO Kits HN Suspension
PS015-081018

 View as PDF

Product Spotlight


KEY TO EFFICIENT REPAIRS COMES WITH HAVING THE RIGHT PARTS TO DO THE JOB.

  • Ensure you have all the right parts
  • One part number to stock
  • Steamline the ordering process

For additional information about the Haulmaax® kit and suspension or other popular kits and suspensions, visit the following:

  • www.atrobushing.com - Search “HN”
  • www.vimeo.com/user84803198
  • www.youtube.com - Search ATRO Bushing

Note: Failure to properly shim will force the load springs to accept the full load and prevent the auxiliary spring from engaging and carrying the significant portion of the load it is designed and required to carry. This produces additional stress on the load pads and may cause premature failure and could void warranty. Do not mix ATRO suspension components with other manufacturer’s components. Doing so will adversely affect ride quality and may cause premature component failures.

KT50-25004 HN® Suspension Kit
Contains:
  • (1) LP50-24000
    • 2-Bolster Springs
  • (1) LP50-24974
    • 1-Spring Pad; 3-Bolts; 3-Locknuts
  • (16) Bolts
  • (16) Locknuts
  • (32) Flat Washers
KEY PART Auxillary Spring & Shim
  • If the height of the unloaded auxiliary spring is 3” or less, the auxiliary spring should be replaced by Part Number LP50-24974.
  • If shim is worn more than 1/8”, the shim should be replaced.
  • Measure distance between auxiliary spring shim (Part Number MS50-29791) and bottom of auxiliary spring (Part Number LP50-24974). Gap should not be larger than 3/8”.
KT50-25003 Hendrickson Haulmaax Suspension Kit
Contains:
  • (4) LP50-24179
    • 8-Bolster Springs; 4-Spacers;
    • 4-Flange Bolts; 36-Flange Nuts
  • (1) LP50-24902
    • 1-Spring Pad; 3-Bolts; 3-Locknuts
    • 2-Shims; 6-Bolts; 6-Locknuts
  • (1) MS50-29891
    • 4-Wear Plates
SK62-50340 Mack Insulator Kit
Contains:
  • (1) SK50340-HW
    • 4-MA36500 Upper Pads;
    • 4-MA36000 Lower Pads;
    • 4-Bolts, 7/8”-9UNC 4”;
    • 2-Bolts, 7/8”-14UNF 5”;
    • 12-Locknuts; 16-Flat Washers
  • (8) MS62-29246 Insulator Spacer Blocks
KT62-62216-HT Mack Isolator Kit-High Temp
Replaces:
  • Mack 204SX216
CONTAINS:
  • (8) PL1017-HT Transmission Mounts
  • (4) Bolts
  • (8) Washers
  • (4) Locknuts
EM75-61001-HT Peterbilt Air Cooler Mount Kit-High Temp
Replaces:
  • PACCAR N4751001
CONTAINS:
  • (4) Polyurethane Mount Bushings
  • (4) Polyurethane Washers
  • (4) Flat Washers
  • (8) Bolts
  • (4) Locknuts
PB00-26839 Lift Axle Bushing Kit
Replaces:
  • Various OEM R008839
  • (16) PB00-36314 Flange Bushings
  • (8) Inner Sleeves
  • (8) Bolts
  • (8) Flat Washers
  • (4) Locknuts
MM75-62001-HT Peterbilt Rear Motor Mount Kit-High Temp
Replaces:
  • Peterbilt MR1001 (Motor Mount ONLY)
CONTAINS:
  • (4) MM75-62372-HT Motor Mounts
  • (4) Bolts
  • (4) Snubber Washers
  • (8) Flat Washers
  • (4) Locknuts
Qty Per Axle: 2

PS015-081018 ATRO Kits HN Suspension

ATRO Kits Mack Camelback
PS016-081018

 View as PDF

Product Spotlight


KEY TO EFFICIENT REPAIRS COMES WITH HAVING THE RIGHT PARTS TO DO THE JOB.

  • Ensure you have all the right parts
  • One part number to stock
  • Steamline the ordering process

For additional information about the Haulmaax® kit and suspension or other popular kits and suspensions, visit the following:

  • www.atrobushing.com - Search “Mack”
  • www.vimeo.com/user84803198
  • www.youtube.com - Search ATRO Bushing

NOTE: Do not mix ATRO suspension components with other manufacturer’s components. Doing so will adversely affect ride quality and may cause premature component failures.

SK50340-HW Mack® Suspension Kit
Contains:
  • (4) MA36000 Load Pad, Lower
  • (4) MA36500 Load Pad, Upper
  • (4) Bolts, 7/8”-9UNC 4”
  • (12) Bolts, 7/8”-14UNF 5”
  • (12) Locknuts
  • (16) Flat Washers

KEY PART

LOAD PADS
  • ATRO’s proprietary low bounce polyurethane takes the bounce out and acts to absorb shock; significantly improving ride
  • Less shock reduces cab damage and T-leaf breakage
  • Chemically resistant to environmental contaminates
KT50-25003 Hendrickson Haulmaax Suspension Kit
Contains:
  • (4) LP50-24179
    • 8-Bolster Springs; 4-Spacers;
    • 4-Flange Bolts; 36-Flange Nuts
  • (1) LP50-24902
    • 1-Spring Pad; 3-Bolts; 3-Locknuts
    • 2-Shims; 6-Bolts; 6-Locknuts
  • (1) MS50-29891
    • 4-Wear Plates
KT50-25004 Hendrickson HN Suspension Kit
Contains:
  • (1) LP50-24000
    • 2-Bolster Springs
  • (1) LP50-24974
    • 1-Spring Pad; 3-Bolts; 3-Locknuts
  • (16) Bolts, 7/16”-20x 1.25”
  • (16) Locknuts
  • (32) Flat Washers
KT62-62216-HT Mack Isolator Kit-High Temp
Replaces:
  • Mack 204SX216
CONTAINS:
EM75-61001-HT Peterbilt Air Cooler Mount Kit-High Temp
Replaces:
  • PACCAR N4751001
CONTAINS:
  • (4) Polyurethane Mount Bushings
  • (4) Polyurethane Washers
  • (4) Flat Washers
  • (8) Bolts
  • (4) Locknuts
PB00-26839 Lift Axle Bushing Kit
Replaces:
  • Various OEM R008839
  • (16) PB00-36314 Flange Bushings
  • (8) Inner Sleeves
  • (8) Bolts
  • (8) Flat Washers
  • (4) Locknuts
MM75-62001-HT Peterbilt Rear Motor Mount Kit-High Temp
Replaces:
  • Peterbilt MR1001 (Motor Mount ONLY)
CONTAINS:
  • (4) MM75-62372-HT Motor Mounts
  • (4) Bolts
  • (4) Snubber Washers
  • (8) Flat Washers
  • (4) Locknuts
Qty Per Axle: 2

PS016-081018 ATRO Kits Mack Camelback

ATRO Kits Kenworth Motor Mount Kit
PS017-081418

 View as PDF

Product Spotlight


KEY TO EFFICIENT REPAIRS COMES WITH HAVING THE RIGHT PARTS TO DO THE JOB.

  • Vibration dampening polyurethane
  • High strength inner steel inserts
  • Chemically resistant to environmental contaminants such as oil, fuel, road salt, cleaning solvent.
  • ATRO HT Mounts provide improved performance in high heat applications.

For additional information about the ATRO and our quality products, visit us online at ATRObushing.com

KT59-62004-HT

Kenwiorth ® Motor Mount Kit w/Hardware, Read High Temperature Mounts
Application: T-600, T-800 Motor Mount
Replaces:
  • Kenworth K066-377 (no hardware)
  • Kenworth K066-421 (no hardware)
Contains:
  • (2) Motor Mounts, Lower
  • (2) Motor Mounts, Upper
  • (2) Wear Pads
  • (2) Wear Sleeves
  • (2) Bolts
  • (4) Flat Washers
  • (2) Locknuts

In 2007 and later trucks, high temperatures from EGR/SCR systems are effecting the performance of engine and exhaust mounts. ATRO’s High Temperature (HT) polyurethane extends the life cycle of mounts in these extreme heat conditions.

Available in Genuine Blue: Part # KT59-62001-HW

MM59-62002 Kenworth Motor Mount Kit
REPLACES:
  • Kenworth mount only
  • K066-247, >K066-282, K066-320, K506-70NR
CONTAINS:
  • (2) PL1012 Motor Mount
  • (4) Bolts
  • (4) Locknuts
  • (8) Washers
KT59-62003-HT Kenworth Rear Motor Mount Kit-High Temp
REPLACES:
  • Kenworth K066-423
CONTAINS:
  • (2) Motor Mounts, Upper
  • (2) Motor Mounts, Lower
  • (2) Bolts
  • (2) Locknuts
  • (4) Flat Washers
Available in Genuine Blue: Part # KT59-62002-HW
MM46-62000 Freightliner Rear Motor Mount Kit
REPLACES:
  • Freightliner BCD 27330 2
CONTAINS:
  • (2) MM46-62001
    • 2-Upper Mounts
    • 2-Lower Mounts
  • (2) Bolts
  • (4) Washers
  • (2) Locknuts
Available in Genuine Blue: Part # KT59-62002-HW
MM55-62005 International Rear Motor Mount Kit
REPLACES:
  • Various International
CONTAINS:
MM62-622M2 Mack Front Motor Mount Kit
REPLACES:
  • Mack 20QL312M2 (Motor Mount ONLY)
CONTAINS:
  • (2) PL1131 Motor Mount Kit, Front
    • 2-Polyurethane Bushings
    • 2-Washers
    • 1-Inner Sleeve
  • (2) Bolts
  • (2) Locknuts
MM75-62001-HT Peterbilt Rear Motor Mount Kit-High Temp
REPLACES:
  • Peterbilt MR1001 (Motor Mount ONLY)
CONTAINS:
  • (4) MM75-62372-HT Motor Mounts
  • (4) Bolts
  • (4) Snubber Washers
  • (8) Flat Washers
  • (4) Locknuts
Available in Genuine Blue: Part # MM75-62001)

PS017-081418 ATRO Kits Kenworth Motor Mount Kit

Chalmers Suspension
PS018-101518

 View as PDF

Product Spotlight


Chalmers walking beam-style tandem axle rear suspensions use two large elastomeric load springs and eight large torque rods, 4 upper and 4 lower. This design allows for a large degree of articulation so the load is equalized while keeping the tires in contact with the ground.

ATRO load springs provide key benefits over rubber

  • Resistant to chemicals (lime, corrosive solvents, road wash)
  • Better load handling and ride characteristics than OEM rubber and other polyurethane brands
  • Will not take a permanent compression set like rubber springs, keeping ride height accurate and driveline angles in spec
PART NUMBEROEM PART NUMBERAXLE RATING
LP19-24002OEM #1500220,000 lbs
LP19-24015OEM #1501515,000 lbs
LP19-24026OEM #1502626,000 lbs

ATRO torque rod bushing options:

ATRO’s 2-piece torque rod bushings make installation easier and faster. With limited installation clearance, 2-piece bushings are placed on each dowel pin on opposite sides and ends. Then the rod with the other halves loaded are positioned on the dowels. Finish the repair by placing and tightening the spigot cap.

Tech Tip:

Change one rod at a time! Otherwise, axles will slide and make re-installation of rods very difficult.

BOLT SIZEASSEMBLY TORQUE FT. LBS.
3/8"35
1/2"65
5/8"135
3/4"250-280*

  • Rubber load springs, subject to chemical attack will take a compression set over time. This negatively affects the vehicle’s ride height, which puts the angle of the driveline out of OEM specs, resulting
  • Torque rod bushings

Chalmers Suspension Componenents

CHALMERS SUSPENSIONLOAD CUSHIONRESTRICTOR CAN2-PIECE OPTION1-PIECE OPTIONOVERSIZE OPTIONSPIGOT CAP
300 Trailer SuspensionLP19-24002 (8.0Hx9.5OD)MS19-29028 Standard or MS19-29029 High StabilityPL1047TH19-22128TH19-22129Type '0' MS19-29002
500 Truck SuspensionLP19-24015 (8.0Hx8.5OD) LP19-24010 (8Hx7-OD)N/APL1047TH19-22128TH19-22129Type '0' MS19-29002
600 Truck SuspensionLP19-24002 (8.0Hx9.5OD)MS19-29028 Standard or MS19-29029 High StabilityPL1047TH19-22128TH19-22129Type '0' MS19-29002
700 Truck Suspension 46KLP19-24002 (8.0Hx9.5OD)MS19-29028 Standard or MS19-29029 High StabilityPL1047TH19-22128TH19-22129Type '2' MS19-29055
700 Truck Suspension 60KLP19-24002 (8.0Hx9.5OD)MS19-29028 Standard or MS19-29029 High StabilityPL1046TH19-22010PL1049Type '2' MS19-29055
800 Tandem Suspension 40KLP19-24002 (8.0Hx9.5OD)MS19-29028 Standard or MS19-29029 High StabilityPL1047TH19-22128TH19-22129Type '1' MS19-29201
800 Tandem Suspension 50K-58KLP19-24002 (8.0Hx9.5OD)MS19-29028 Standard or MS19-29029 High StabilityPL1046TH19-22010PL1049Type '2' MS19-29055
800 Tandem Suspension 65KLP19-24026 (8.0Hx10.75OD)N/APL1046TH19-22010PL1049Type '2' MS19-29055
800 Tandem Suspension 80KLP19-24026 (8.0Hx10.75OD)N/APL1046TH19-22010PL1049Type '2' MS19-29055
800 Tandem Suspension 100KLP19-24026 (8.0Hx10.75OD)N/APL1046TH19-22010PL1049Type '2' MS19-29055
1000 Single Axle Suspension 23KLP19-24010 (8Hx7-OD)N/APL1047TH19-22128TH19-22129Type '1' MS19-29201
1000 Single Axle Suspension 30KLP19-24015 (8.0Hx8.5OD)N/APL1046TH19-22010PL1049Type '2' MS19-29055

PS018-101518 Chalmers Suspension

ATRO Bumper Choices
PS019-102418

 View as PDF

Product Spotlight


Today's typical rubber bumpers do not last very long and may be worn out in six to twelve months. ATRO's polyurethane bumpers have been proven to last as much as 15 times longer than rubber.

THINGS TO CONSIDER

  • Labor Cost
  • Downtime
  • Trailer Damage

Changing out a simple trailer bumper can present a technician with unexpected problems. Many of today’s bumpers are mounted into a sealed bumper frame that contains the stop/tail/turn lamps. Often, a lamp will need to be removed to gain access to the rusted nuts on the inside of the trailer bumper frame. This is further complicated when the lamp is secured with a riveted lock ring, common with the newer LED powered stop/ tail/turn lamps. The bumper removal process usually takes a minimum of 20 minutes and as much as 45 minutes to complete and often the lamp gets damaged in the process.


PS019-102418 ATRO Bumper Choices

PS004-091716 Fontaine 5th Wheel Bushings and Kits

 View as PDF

Product Spotlight


PS004-091716 Fontaine 5th Wheel Bushings and Kits

ATRO Small Eye Torque Rods vs. OE Small Eye Torque Rods
PS003-090919

 View as PDF

Product Spotlight


PS003-090919 ATRO Small Eye Torque Rods vs. OE Small Eye Torque Rods
