PB50-36001 | Pivot Bushing w/Shear Bolt | ATRO Engineered Systems, Inc.

PB50-36001 | Pivot Bushing w/Shear Bolt

PB50-36001 - Pivot Bushing w/Shear Bolt


PB50-36001 — Pivot Bushing w/Shear Bolt

{{exactOrNear}} to {{searchTerm}}


Item Description
ATRO # PB50-36001
VMRS #
Category Trailer
Description Pivot Bushing w/Shear Bolt
Availability
Your Price ($USD)
Shipping Weight 13.62 lbs
UPC Code 751354038194
Part Dimensions Sleeve Length=6 3/4" Bushing Width=5.75" at Sleeve
Inside Diameter 1 1/4"
Outside Diameter — Reference
Outside Diameter — Large 5 7/8"
Outside Diameter — Small
Package Dimensions (in) 8.4 (L) x 8.4 (W) x 7.9 (H)
Package Type BOX K
Qty Per Vehicle 2 per axle
Contains Bushings
Includes Kit Components
(1) Pivot Bushing
(2) Shims
Misc. Specs
Bolt: 7/8"
Includes Shear Bolt
Install Tool PT50-59307
Removal Tool
Tool Handle
Misc. Tool
Documentation
Warranty 3 Years

    Additional specs or content for this part go here.
    PB50-36001

    Enter the Custom Torque Rod C-C length: (example 29 1/2)

      / "

    Parts Cross Reference

    OEM/BrandCross ReferenceApplication Notes
    AutomannMHS736UB
    AutomannMHS736
    Dayton Parts334-1576Rubber
    EuclidE-10729A
    FlaggHT245
    GaffGAFF13624Near Cross
    With Standard Bolt
    GaffGAFF13510Exact Cross
    GaffGAFF13628Exact Cross
    With Shear Bolt
    Hendrickson Auxiliary AxleS-24691Quick Align; Intraax; Vantraax; HT Series; HLM Series
    Watson Chalin17993112
